Halo: Campaign Evolved Hits 60FPS on Series X; Handhelds Scrape 30-40

Halo: Campaign Evolved runs a rock-solid 60FPS on Xbox Series X in performance mode, with hardware ray tracing and the full Unreal Engine 5 visual kit active, based on a preview build analysed by Digital Foundry. The console version holds its target through two layers of dynamic resolution scaling that average 50-75% of the output resolution, putting the rendered image “often at 1080p-ish” but reading as clean to the eye.

That Series X headline masks a more uneven picture for the rest of the launch lineup. Xbox Series S was not ready for the cameras, the ROG Xbox Ally X scrapes 30-40FPS on “Very Low” settings in handheld mode, and a Steam Deck is unlikely to reach a stable 30FPS, per Digital Foundry’s published speculation. The game ships on July 28, 2026, with early access on July 23, 2026. The wider release will be the first Halo on a PlayStation console and the first on Unreal Engine 5.

Series X Hits a Rock-Solid 60FPS

The dynamic resolution pattern is standard: render the frame at a lower internal resolution and scale up to output when GPU headroom runs out. What Halo Studios adds on top, Digital Foundry’s first-look video reports, is a translucency pass that varies the resolution of transparent effects on its own budget, so the cost of an alpha effect like a window, muzzle flash, or energy shield no longer eats the same share of every frame. The 30FPS Quality Mode is in the final build but was off-limits for the preview hands-on, so the only reading available for now is the 60FPS performance path.

The translucency pass is a way to spend the frame budget on solid geometry first and alpha effects second, and it is unusual to see it called out by name in a console performance preview. Halo Studios’ choice to spend the headroom on a second dynamic layer for transparent effects, rather than just dropping the overall resolution further, is a deliberate trade. The 15-minute first-look performance analysis from Digital Foundry shows the technique in side-by-side captures from The Silent Cartographer and Assault on the Control Room, the two remade campaign missions the outlet was given access to. The build Digital Foundry tested is the early-access build that pre-order Premium Edition buyers will play on July 23, 2026, with the wider release following on July 28, 2026.

The analysis is from Digital Foundry, which is now fully independent, and was published on June 11, 2026, the day the technical preview went live. The same preview, hosted and framed by Fraser Gilbert at Pure Xbox, is the source most of the early coverage has been working from.

The Translucency Pass That Saves Frames

The translucency pass treats alpha effects as a separate resolution layer from the main render, scaling them down further when the frame budget is tight. That means a window, a muzzle flash, or an energy shield takes fewer pixels per frame than a wall, a marine, or a Warthog, and the loss is most visible on the smaller alpha effects where the resolution drop reads as soft edges. Digital Foundry’s preview shows the technique paying off in the heavier moments of The Silent Cartographer, where combat and effects density spike, and the framerate still holds the 60FPS line. The translucency pass is a known engine trick, but few UE5 console builds call it out as a load-bearing part of the framerate. Halo Studios chose to spend the headroom on alpha fidelity rather than on a third solid-geometry layer, and the result on Series X is 60FPS with hardware ray tracing at the same time.

The trade is image quality on the alpha side, which is sometimes visible in motion. The mid-tier effect is a faint softness on energy weapons and shield bubbles in combat. The 30FPS Quality Mode, when it ships in the final release, is expected to give the translucency pass more room, since the per-frame budget doubles.

The Visual Trade-Off: Lumen Denoising Is Hard to Hide

The dynamic resolution work is paired with the move to Unreal Engine 5, which brings the engine’s signature lighting tech with it. Digital Foundry’s preview covered The Silent Cartographer and Assault on the Control Room, two of the remade campaign missions, and the outlet calls the visual jump “light years beyond Halo Anniversary.” Warthog-driving around the Silent Cartographer island shows reflections of the surrounding rock in the surf and dramatic sunlight through the canopy, with marine detail at a level the original engine never reached. The Silent Cartographer starts with a pre-rendered 30fps cinematic that runs in-engine but at half the framerate, a one-line surprise the technical preview flagged.

The catch is Lumen denoising, and it shows. Sparkling, boiling, and temporal noise artefacts appear throughout the preview, especially in darker scenes, and the artefacts also show up on high-end PC hardware as well as the Xbox console.

The UE5 visual kit Halo Studios is showing off in the preview:

• Lumen global illumination
• Unreal MegaLights
• Hardware ray-tracing
• Volumetric lighting
• Re-recorded cinematics and audio

The Xbox Series X version exhibits only middling image quality because of these effects, which is the cost of running the full UE5 stack on a console GPU. The atmosphere of the original biome, the team notes, is intact, with the granular detail on the Warthog and the marines matching the new environmental fidelity. The trade-off is the kind of edge-case artefact Lumen users have been documenting since the engine launched, and it is a real cost on Series X, not a PC-only issue. The denoising, the outlet writes, “detracted from the overall coherence of the image” even when running on high-end PC. Art director Chris Matthews cited Lumen and Nanite as the reason for the engine swap, and the visual jump is real, even if the denoising is the visible cost, per the full first-look written preview.

Xbox Series S Isn’t Ready, and PC Skips Below Native 4K

The smaller Xbox console is the first platform where the preview leaves a question open. Digital Foundry says the Series S version is “technically playable but we were told it wasn’t ready yet,” meaning the build was not finalised in time for the technical hands-on. The Xbox Games Showcase on June 7, 2026 confirmed the game is targeting Xbox Series X/S, PlayStation 5, and PC on July 28, 2026, with a first-on-PlayStation release for the franchise.

The PC side scales, but it scales down faster than the spec sheet suggests. The YouTuber jackfrags tested an early build on an AMD Ryzen 9 9950X3D with an NVIDIA GeForce RTX 5090, and at native 1440p with DLAA and Ultra settings, the framerate starts at 120FPS in the opening area, drops to 100FPS outdoors, and lands in the 90s the moment the player takes control of a tank. That is the top of the consumer PC stack in 2026, and it cannot reach a native 4K Ultra framerate. The official PC specifications Microsoft published list an NVIDIA GeForce RTX 4080 for 4K at 60FPS on Ultra, with 32GB of RAM and 16GB of VRAM. The full official spec table is below.

Digital Foundry’s own mid-range PC test was a Ryzen 5 5600X with 16GB of DDR4-3200 RAM and an RTX 4060 graphics card, which exhibited CPU bottlenecking in The Silent Cartographer at 1440p DLSS balanced and High settings. Assault on the Control Room ran a lot better on the same setup, with the bottleneck tied to lots of enemy AI in play, a load case the Xbox build does not show.

An RTX 5090 at 4K 60FPS with DLAA and max settings hit only 50% GPU utilisation, which tells the story the spec table hints at. Lumen is a form of ray tracing, and ray tracing at native 4K with full settings is not in scope for 2026 hardware. The Series S framerate question, and whether the 4K/60 Ultra spec actually holds, are both open for the early-access build on July 23, 2026.

On Handhelds, the Headroom Disappears

The preview that hits 60FPS on a TV struggles in the hand, where the same build defaults to 1080p at very low settings. Digital Foundry tested the game on the ROG Xbox Ally X in handheld 25W mode, and the analysis says the framerate is “north of 30fps” even in The Silent Cartographer, which is the heavier of the two preview missions, and the game “looks OK on the handheld screen” because the smaller display masks the lower resolution. The non-X ROG Ally uses “very, very similar” hardware, so a similar result is expected on the smaller model. Pure Xbox, which hosted an early look at the Digital Foundry video, frames the handheld number as “around 30-40FPS right now on ‘Very Low’ settings,” a wide band that captures the open-question nature of the build.

The Steam Deck is where the headline risk lives. Digital Foundry says a Steam Deck “might struggle more to hit 30fps” on hardware the outlet described as “less powerful” than the Ally X, which is the published speculation, not a measured number, on a device that has been the most-shipped PC handheld of the generation. A Halo: Campaign Evolved that holds 60FPS on a Series X but chokes on a Deck is a real platform signal for the multiplatform push.

Framerate snapshot from the preview build:

• Xbox Series X (performance mode): 60FPS target, hardware RT, DRS 50-75%
• Xbox Series X (quality mode): 30FPS target, not previewed
• PC RTX 5090 at 4K Ultra DLAA: ~50% GPU utilisation
• PC RTX 5090 at 1440p Ultra DLAA: 90-120FPS
• PC RTX 4060 at 1440p DLSS Balanced High: CPU-bound in Cartographer
• ROG Xbox Ally X 25W handheld: 30-40FPS, very low, 1080p TSR
• Steam Deck: under 30FPS expected (DF speculation)

The two preview missions, The Silent Cartographer and Assault on the Control Room, are the heaviest in the original campaign, so a cleaner indoor mission might lift the framerate further. Halo Studios still has time to ship a build with better low-end PC scaling before the July 23 early-access window opens. The non-X Ally’s near-identical hardware means the result on the smaller model will likely track what the Ally X shows, and the Deck, which is the outlier, is the open question for PC handheld fans. The same preview where Series X held 60FPS is the same preview where Steam Deck owners should expect a tough launch.

Why This Preview Reads as a Test, Not a Verdict

Halo: Campaign Evolved is the inaugural project for Halo Studios, the studio formerly known as 343 Industries, which rebranded in October 2024 and pivoted from its bespoke Slipspace Engine to Unreal Engine 5 in the same move. It is also the first Halo project to ship on Unreal Engine 5, and the first Halo game to launch on a PlayStation console, a multiplatform shift the studio framed as a way to introduce the series to new players for the franchise’s 25th anniversary.

The campaign remakes Halo: Combat Evolved from 2001 with redesigned missions, three new missions featuring Master Chief and Sgt. Johnson, re-recorded voice performances from the original cast, and the original score by Martin O’Donnell and Michael Salvatori remastered. The competitive multiplayer has been cut; four-player online co-op and crossplay remain, with two-player split-screen on consoles. The Premium Edition is priced at $79.99, $20 more than the Standard Edition, and Premium pre-orders open early access on July 23, 2026, according to the official game store page. Digital Foundry’s preview stops where the build stops, and three open questions for the early-access window are the Quality Mode frame budget, the Series S final-build framerate, and whether the Steam Deck can climb back above 30FPS. The 60FPS Series X result is the headline the launch is selling on, and the rest of the platform list is the test that determines whether the engine swap sticks.
